Aventon Level 3 Electric Bike – Step-Over Frame

Description

Take your commutes to the next LEVEL. The all new Level 3 comes fully equipped with everything you need to trade your daily drives for daily rides. A rear rack and fenders ensures you can carry necessities while staying clean and dry during your rides. A front suspension fork and suspension seat post provide maximum comfort on rougher terrain. Our ACU technology provides peace of mind with GPS tracking, auto-lock, unusual movement detection, alarm system, and much more to keep your bike safe and secure. Comfortable geometry paired with an adjustable stem ensure the perfect fit, while the implementation of Ride Tune capabilities along with adjustments to Level 3’s motor power curves provide up to an additional 10 miles of range compared to its predecessor. Ditch the traffic, and elevate your daily commutes with the Level 3.

Technical Overview

The Level 3 comes out of the box as a Class 2 ebike, with pedal assist and throttle. It can be unlocked to a Class 3 ebike. The Level 3 will also operate with the throttle unplugged and removed, should you want to ride in an area where throttles are prohibited or only Class 1 bikes are permitted. Aventon ebikes are built to the IPX4 water-resistant standard. IPX4 means that your bike is resistant to water splashes from any direction. This means it’s OK to ride your ebike in light rain. It won’t be harmed by spray from a wet road or raindrops. Your ebike is not intended to be exposed to prolonged rain, be submerged, or subjected to a pressurized spray. Don’t use a pressure washer or sprayer to clean your ebike. *Max range determined using PAS 1 throughout flat terrain with a rider weight of 160 lb.
TECHNICAL SPECIFICATIONS GENERAL INFO MODEL Level 3 Step Through Commuter Ebike WEIGHT:  67lbs TOTAL WEIGHT LIMIT:  300 lbs
EBIKE CLASS:  Class 2 Ebike WATER RESISTANCE:  IPX4 RANGE:  Up to 70 Miles BATTERY SAFETY CERTIFICATIONS:  Certified to UL 2271 SAFETY CERTIFICATIONS:  UL Safety Certified
UL 2849 IDEAL USE:  Commuting PEDAL ASSIST:  3 Levels (with Ride Tune Customization) FRAMESET FRAME 6061 Aluminum, Gravity Cast Front Triangle FORK Aventon Suspension Fork, 80mm travel, w/ lockout,coil spring. 15x100mm thru-axle, 43mm offset REAR SPACING 142mm FORK SPACING 110mm FRAME STYLE Step-Over WHEELSET FRONT WHEEL 27.5in, 13g, 36hole, double wall Aluminum, Thru axle, Schrader Valve, black REAR WHEEL 27.5in, 12g, 36hole, double wall Aluminum, Nutted Hub Drive Motor, Scharder Valve, black TIRES Kenda Kwick Seven-5 Sport K1052-006 27.5 x 2.20 EBIKE SYSTEM MOTOR:  36V, 500W (sustained), 864W (peak) MOTOR TORQUE:  60Nm DISPLAY:  Aventon BC280 BATTERY:  Removable Internal Lithium-ion. 36V, 20Ah, 733Wh, LG 21700 cells BATTERY WEIGHT:  8.7lbs CONTROLLER:  36V, 24A THROTTLE:  Aventon LH Handlebar Mounted SENSORS:  Double Sided Bottom Bracket Torque Sensor CHARGER:  36V Output: 42V/ 4A CHARGING TIME FROM 0% TO 100%:  5 hours LIGHTS:  Front and rear lights integrated SPEED:  Class 2 FRONT BRAKE:  Magura AT-2 Hydraulic disc brake REAR BRAKE:  Magura AT-2 Hydraulic disc brake FRONT BRAKE ROTOR:  Magura MDR-A 180mm 6 Bolt Rotor REAR BRAKE ROTOR:  Magura MDR-A 180mm 6 Bolt Rotor REAR DERAILLEUR: Shimano Altus RD-M310
INCLUDED ACCESSORIES:  REAR RACK (WEIGHT LIMIT 60lbs)
